Digital Temperature Controller (48 x 96 mm)
last update: October 23, 2023
(1) Control Output Assignment
If there is no control output 2, an auxiliary output is used as the cooling control output.
If there is a control output 2, the two control outputs are used for heating and cooling.
(It does not matter which output is used for heating and which output is used for cooling.)
(2) Control
If PID control is used, you can set PID control separately for heating and cooling.
This allows you to handle control systems with different heating and cooling response characteristics.
(1) Control Output Assignment
An auxiliary output is used as the cooling control output.
(2) Control
If PID control is used, you can set PID control separately for heating and cooling.
This allows you to handle control systems with different heating and cooling response characteristics.
Model |
---|
E58-CIFQ2 |
Model |
---|
E58-CIFQ2-E |
Model |
---|
E53-COV24 (3pcs) |
Note: The Terminal Covers E53-COV24 are provided with the Digital Temperature Controller.
Model |
---|
Y92S-P9 |
Note: This Waterproof Packing is provided with the Digital Temperature Controller.
Model |
---|
Y92A-49N |
Model |
---|
Y92S-P7 |
Note: This Front Port Cover is provided with the Digital Temperature Controller.
Model |
---|
Y92F-51 (2pcs) |
Note: This Mounting Adapter is provided with the Digital Temperature Controller.
Hole diameter | Model |
---|---|
5.8 mm | E54-CT1 |
5.8 mm | E54-CT1L * |
12.0 mm | E54-CT3 |
12.0 mm | E54-CT3L * |
* Lead wires are included with these CTs. If UL certification is required, use these CTs.
Model |
---|
EST2-2C-MV4 |
